Autel MaxiBAS BT506 Battery and Electrical System Analysis Tester Used with Autel MaxiSys Supports iOS & Android

Highlights

• Out-of-vehicle Battery testsing
• Test Flooded, AGM, AGM_Spiral, EFB and GEL Batteries
• Battery Health Report / Temperature Compensation / Cloud-based Service
• Battery Ratings: CCA, CA, MCA, JIS, DIN, SAE, IEC, EN, EN2, BCI, GB
• In-vehicle testing of Battery, Starter, Charging system voltage (not amps)
• Test 6- and 12-volt Batteries: 100 - 2000 CCA
• Test 12- and 24-volt Cranking/Charging Systems

Specifications

Connectivity: USB 2.0, Type C and Bluetooth V3.0 BR/EDR+ V4.2 LE Dual-Mode
Input Voltage: 5 V DC
Working Current: <   150 mA at 12 V DC
Internal Battery: N/A
CCA Range: 100   to 2000 A
Voltage Range: 6   to 36 V
Working Temperature: -10°to   50° C (14° to 122° F)
Storage Temperature: -20°   to 60° C (-4° to 140° F)
Dimension (L x W x H): 107 mm (4.21“) x 75 mm (2.95”) x 26 mm (1.02”) (clamp cable not included)
Weight: 320g (0.7 lb.)

Packing List

1set X Autel MaxiBAS BT506
The BT506 does not have a screen!
To perform testing and display test results the BT506 must be used with an Autel MaxiSys tablet or other smart device (free iOS or Android apps available).

Battery Test App QR Code:
